1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine

1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine

Introduction

The Dowell3d was created to make industrial 3D printing of large-scale objects and prototype as easy as possible. It can simplify your workflow and provide the quality results you need.

It is equipped with our latest technology, simple to use, powerful, and provides the most cost-effective way for disruptive enterprises to adopt 3D printing.

Dowell 3d printers will be your best choice with no doubt!

1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine factory

Specification
Model
DM10-20Plus
Printing volume
1000*1000*2000mm
Frame
60mm aluminum section
Printing bed
6mm tempered glass
Nozzle diameter
0.4/0.8/1.6mm
Nozzle temperature
0-380℃
Bed temperature
0-100℃
Location accuracy
0.002mm
Layer height accuracy
0.04-0.6mm
Extrusion flow rate
Max 400g/hour
Operation firmware
R&D Based On Klipper
Operation interface
7'' full color touch screen
File format
STL/OBJ/GCODE/JPG
Filament available
2.85mm PLA,PETG,ASA,ABS,PVA,TPU,WOOD,CARBON FIBER,etc.
Connection
SD Card/ U Disk/ WIFI
Input power
110/220V
Basic functions
*Auto leveling *Filament sensor
*Remote control *Wifi connection *Visible Printing status
*Visible temperature graph *Installable external camera
*Configuration editable *Z-offset adjustment
*Speed & extrusion & cooling adjustment
*Gcode viewer *History record *Emergency stop button
Optional
*60°c Enclosure
*Customize printing size
Product Description
Dowell 3D printer is an excellent solution with simple setup and intuitive operation. Whether you work in aerospace, automotive, power, energy, furniture, outdoor advertising, sculpture, statue, or any other industry that requires high-performance parts, Dowell 3d printers can unlock endless possibilities.
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine manufacture
380°c HIGH-TEMP NOZZLES
Dowell extruder features a dual drive gear system and metal heating block for enhanced heat transfer and high temperature compatibility. It uses thermal insulation and an upgraded temperature sensor to support printing temperatures up to 380°C.
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine details

100℃ HIGH-TEMP PLATFORM

DM Plus comes standard with a 6mm tempered glass platform heated bed, which has high surface flatness, is not easy to deform, has good thermal conductivity, strong adhesion, and also easy to clean, Suitable for high-temperature printing materials.

1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine supplier

Fast Printing speed

The affordable Dowell 3D printer enables rapid prototyping, allowing users to create prototypes in a fraction of the time, turning ideas into reality faster for mass production.
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine supplier
Built-in remote module
DOWELL3D printer is equipped with remote maintenance modules to analyze possible anomalies and to reduce the possibility of downtime for the advantage of productivity. The remote management feature includes sending software updates to allow the DOWELL 3D Printer to evolve over time, acquiring new features, parameters, and intelligent functions.
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine manufacture

64-Points mesh bed auto leveling

First, the 4 corners are detected, and then the 8*8, 64 points rectangular detection of the flatness of the bed is carried out. It adjusts the inclination by rotating the screw and automatically compensates for unevenness to ensure perfect flatness before each printing job.
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine details

Noiseless Drive

DM Plus series 3d printer has both the advantages of silence and high efficiency. Say goodbye to traditional mechanical noise, which will have no impact on your work and personal life.

Strong Frame Structure

DM Plus series 3d printer all using high quality 60mm thicken aluminum alloy as the main body, is reinforced with diagonal supports to ensure stronger stability in the printing process.

1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine manufacture 1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine manufacture

Industrial Grade Ball Screw & Linear Guide Rails

Industrial-grade movements are used to achieve the mechanical precision of typical machine, improving the production speed, accuracy and repeatability of printed parts.
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine factory

Multi-language 7 inch Tochscreen

The system supports 18 languages, contact us to learn more~

Multiple material printable

Support printing of most materials on the market.
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine factory1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine manufacture
*Extensive Printer Size Options
*In addition to these sizes, you can contact us for customized dimensions tailored to your specific requirements.
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine factory
Customization options
In addition to its fundamental features, DOWELL 3D printers are also equipped with customizable functionalities, allowing users to tailor the printer to their specific needs.
1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine details
Dowell 3d Printer Promises:
*One year warranty *Lifetime maintenance *Factory direct sales *Quality assurance *Technical support


Customer's Printing Cases


1000*1000*2000mm big size industrial sculpture statues 3d printer furniture 3d printing machine factory

Print with Ease, Innovate Infinitely!

DOWELL3D, a manufacturer with a decade of expertise in R&D, production, and global export of large-scale industrial 3D printers. 图片18

FAQ
1-Are you a factory?
Yes, we are a directly manufacturer focus on developing and produce large industrial 3d printers.
2-Payment method
T/T (Bank transfer), Paypal, West union, Credit card, Wechat pay, Ali Pay, T/T
3-Shipping method
DHL, UPS, Fedex, TNT, sea shipping, air freight, by train.
4-What's your lead time?
If the product you order is our standard model, lead time is around14 days; or else lead time is negotiable.
5-How do you guarantee the quality of the printer?
We have 100% tests before shipment. We will supply photos and video of tests before shipment. We can guarantee that our 3D printer will have absolutely no quality problems before shipment. Then we will arrange the shipping under the confirming.
